Remote
The Galaxy 5000 supports the whole of the MGE UPS SYSTEMS remote management system to:
*

provide information on the UPS and its environment

*

controlled shutdown of the operating systems if genset has a malfunction at the time of black out.

Telecommunications:
24 X 7 continuity of service
*

with built in network cards, it can connect to internet for remote supervision

*

it is easily identified by the Enterprise Power Management UPS system supervisor.

Advantages
*

compatible with all types of loads: Leading power factor computer loads, high crest factor loads.

*

fully compatible with generator sets: Apart from high input power factor of the UPS it has a soft start so that a 60kVA UPS only requires a 66kVA* generator set (ignoring others loads supported by genset)

*

securing data with clean server shutdown

*

real time information about UPS status

View Product Specification Order

Best in High Availability power solutions
*

Tried and tested on-line double conversion design with dual source (automatic or manual switching), with quality output waveform (output voltage harmonic distortion less than 2% - THDU) and stable frequency.

Innovation UPS switching technology: IGBT Sixpacks
*

IGBT technology provides cleaner waveforms. The IGBT Sixpack semiconductors used in the Galaxy 5000 are most compact and themost integrated on the market.

Clean, stable output waveform
*

The output voltage from an on-line double conversion UPS is always generated internally, isolating it completely from mains disturbances.

THDI, <3%: supply cost savings and low pollution

The Galaxy 5000 IGBT AC/DC rectifier with power factor correction also uses a Sixpack:
*

very low input current totla harmonic distortion

*

power factor close to unity, even at low loads

Digibat Battery Monitoring: microprocessor based battery management.


DigiBat monitors the power levels, temperature, age and type of battery to adjust the battery charging voltage to surrounding temperture and continuously calculates:

*

the real backup time available.

*

the remaining life expectancy.

DigiBat also:

*

tests the battery system automatically (at intervals that can be pre-set), without affecting the battery capacity.

*

sounds an alarm if any problem is likely to occur.

The optional B1000 or Cellwatch battery monitoring systems monitor the battery systems 24 hours a day and provide predictive fault alarms per each block or cell:

*

continuous voltage measurement for each block or cell

*

continuous internal resistance measurement

*

identification of faulty blocks or cells (trend curves)

*

possibility of replacing individual blocks or cells

*

remote transfer of all data by Ethernet, current loop or J-bus
